4-pin lemo connector (for 010 and 034 cables with icp triaxial pinout)

Cable Connector

Model GW

  • IP

4-pin LEMO connector (for 010 and 034 cables with ICP triaxial pinout)

  • Connector Style: LEMO
  • Connection Type: 4-pin
  • Temperature Range: -40 to 176 °F (-40 to 80 °C)

Specification Notes


English: SI:
Performance
Connector Style LEMO LEMO
Connection Type 4-pin 4-pin
Strain Relief Molded Boot Molded Boot
Environmental
Temperature Range -40 to 176 °F -40 to 80 °C
Maximum Shock 100 g pk 981 m/s² pk
Vibration Survivability 15 g pk 147 m/s² pk
Physical
Electrical Connections (Pin 1) Z axis Z axis
Electrical Connections (Chrome-Plated Brass) Y axis Y axis
Electrical Connections (Pin 3) X axis X axis
Electrical Connections (Out 1) Ground Ground
Electrical Connections (Shell) No Connection No Connection
Housing Material Brass Brass
Size - OD 0.37 in 9.5 mm
Size - Length 1.38 in 35 mm

* All specifications are at room temperature unless otherwise specified.
