low-cost, general purpose, industrial ceramic shear icp® accel, 10 mv/g, 0.5 to 10k hz, top exit, 10 feet integral cable, intrinsically safe, single point iso 17025 accredited calibration

LOW-COST INDUSTRIAL ICP® ACCELEROMETER

Model EX603C10

Add to Quote
  • CE
  • EX
  • IP

Low-cost, general purpose, industrial ceramic shear ICP® accel, 10 mV/g, 0.5 to 10k Hz, top exit, 10 feet integral cable, intrinsically safe, single point ISO 17025 accredited calibration

  • Sensitivity: (±20%)10 mV/g (1.02 mV/(m/s²))
  • Frequency Range: (±3dB)30 to 600000 cpm (0.5 to 10000 Hz)
  • Sensing Element: Ceramic
  • Measurement Range: ±500 g (±4905 m/s²)
  • Weight: 1.8 oz (51 gm)

Additional configurations:

Specification Notes

[1] Conversion Factor 1g = 9.81 m/s².
[2] Zero-based, least-squares, straight line method.
[3] The high frequency tolerance is accurate within ±10% of the specified frequency.
[4] Typical.
[5] Twisted shielded pair.
[6] 1/4-28 has no equivalent in S.I. units.
[7] See PCB Declaration of Conformance PS023 or PS060 for details.

English: SI:
Performance
Sensitivity (±20 %) 10 mV/g 1.02 mV/(m/s²) [1]
Measurement Range ±500 g ±4905 m/s²
Frequency Range (±3 dB) 30 to 600000 cpm 0.5 to 10000 Hz [3]
Resonant Frequency 1500 kcpm 25 kHz [4]
Broadband Resolution (1) 2000 µg 19,620 µm/sec2 [4]
Non-Linearity ±1 % ±1 % [2]
Transverse Sensitivity ≤7 % ≤7 %
Environmental
Overload Limit (Shock) 5000 g pk 49050 m/s² pk
Temperature Range -65 to +250 °F -54 to +121 °C
Temperature Response See Graph %/°F See Graph %/°F [4]
Enclosure Rating IP68 IP68
Electrical
Settling Time (within 1% of bias) ≤3.0 sec ≤3.0 sec [4]
Discharge Time Constant ≥0.4 sec ≥0.4 sec
Excitation Voltage 18 to 28 VDC 18 to 28 VDC
Constant Current Excitation 2 to 20 mA 2 to 20 mA
Output Impedance <150 Ohm <150 Ohm
Output Bias Voltage 8 to 12 VDC 8 to 12 VDC
Spectral Noise (10 Hz) 85 µg/√Hz 834 (µm/sec2)/√Hz [4]
Spectral Noise (100 Hz) 20 µg/√Hz 196 (µm/sec2)/√Hz [4]
Spectral Noise (1 kHz) 5 µg/√Hz 49.1 (µm/sec2)/√Hz [4]
Electrical Isolation (Case) >100000000 Ohm >100000000 Ohm
Physical
Size - Hex 11/16 in 18 mm
Size - Height 4.7 in 119 mm
Weight (without cable) 1.8 oz 51 gm
Mounting Thread 1/4-28 Female 1/4-28 Female [6]
Mounting Torque 2 to 5 ft-lb 2.7 to 6.8 Nm
Sensing Element Ceramic Ceramic
Sensing Geometry Shear Shear
Housing Material Stainless Steel Stainless Steel
Sealing Welded Hermetic Welded Hermetic
Electrical Connector Molded Integral Cable Molded Integral Cable
Electrical Connection Position Top Top
Cable Length 10 ft 3.0 m
Cable Type Polyurethane Polyurethane [5]

* All specifications are at room temperature unless otherwise specified.

TempChart

Accessories
Supplied
081A40 Mounting stud, 1/4-28 x 0.438" long stainless steel screw with hex socket and brass tip 1
ICS-2 Calibration of industrial accel., single-point, 100 Hz reference sensitivity 1
M081A61 Mounting stud, 1/4-28 to M6x1 x 9.65 mm long, BeCu w/shoulder 1

Optional Versions

(M) Metric Mount
Accessories:
Supplied M081A61 Mounting Stud 1

(TO) Temperature Output

English SI
Temperature Output Range 36 to 250 °F 2 to 121 °C
Temperature Scale Factor 5.56 mV/°F + 32 +10 mV/°C
Electrical Connections Acceleration Output
Electrical Connections Ground
Electrical Connections Temperature Output
Electrical Connections Ground
