fatigue load cell, low profile, 200k lbf rated capacity,2 mv/v output, 3 1/2 -8 (f) thd., pt02e-10-6p connector. note: this load cell is calibrated by an independent calibration facility which is a2la accredited to iso 17025

Strain Gage Load Cell

Model 1414-02A

Retrieving Price...

(Pricing valid only in the U.S.)

Add to Cart
Units in Stock Lead Times
More on the way Call for Lead Time
  • IP

Fatigue load cell, low profile, 200k lbf rated capacity,2 mV/V output, 3 1/2 -8 (F) thd., PT02E-10-6P connector. Note: This load cell is calibrated by an independent calibration facility which is A2LA Accredited to ISO 17025

  • Measurement Range: 200 klb (890 kN)
  • Size - Diameter: 12 in (304.8 mm)
  • Size - Height: 9 in (228.6 mm)
  • Electrical Connector: PT02E-10-6P

Specification Notes

[1] FS - Full Scale.
[2] RO - Rated Output.
[3] Calibrated in tension and compression.
[4] Singularly applied, i.e. no other extraneous loads.
[5] Over compensated operating temperature range.
[6] Nominal.
[7] Calibrated at 10 VDC, usable 5 to 20 VDC or VAC RMS.
[8] See Outline Drawing 55808 for complete dimensions.

English: SI:
Performance
Measurement Range (100 x 10^6 cycles) 200 klb 890 kN [1] [3]
Sensitivity (±10 %) 2.0 mV/V 2.0 mV/V [2]
Non-Linearity ≤0.06 % FS ≤0.06 % FS
Hysteresis ≤0.06 % FS ≤0.06 % FS
Non-Repeatability ≤0.02 %RO ≤0.02 %RO
Creep 0.025 % 0.025 %
Static Error Band ≤0.06 % FS ≤0.06 % FS [1]
Eccentric Load Sensitivity ≤0.01 %/in ≤0.1 %/25.4mm
Resonant Frequency 18 kHz 18 kHz
Side Load Sensitivity ≤0.1 %/in ≤0.1 %/25.4mm
Environmental
Overload Limit 600 klb 1779 kN
Load Limit (Side Force, FX or FY) 200 klb 890 kN [4]
Load Limit (Bending Moment, MX or MY) 200k in-lb 23k Nm [4]
Load Limit (Axial Torque, MZ) 200k in-lb 23k Nm [4]
Temperature Range (Operating) -65 to +200 °F -54 to +93 °C
Temperature Range (Compensated) +15 to +115 °F -9 to +46 °C
Temperature Effect on Output (Maximum) ±0.0008 %Reading/°F ±0.0018 %Reading/°C [5]
Temperature Effect on Zero Balance (Maximum) ±0.0008 %FS/°F ±0.0018 %FS/°C [5]
Electrical
Bridge Resistance 350 Ohm 350 Ohm [6]
Excitation Voltage (Recommended) 10 VDC 10 VDC [7]
Insulation Resistance 5 KGOhm 5 KGOhm
Zero Balance ≤1 % FS ≤1 % FS
Physical
Size - Height 9 in 228.6 mm [8]
Size - Diameter 12 in 304.8 mm [8]
Weight 135 lb 61.3 kg
Mounting Thread 3 1/2 - 8 UN-3B No Metric Equivalent
Housing Material Painted Steel Painted Steel
Sensing Element Strain Gage Strain Gage
Mounting Torque 9000 in-lb 1016 Nm
Deflection at Full Scale Capacity 0.001 in 0.025 mm
Electrical Connector PT02E-10-6P PT02E-10-6P
Electrical Connection Position Side Side

* All specifications are at room temperature unless otherwise specified.

Accessories
Optional
182-025A PC06A-10-6S (SR) 1
8315-01-10A 4-conductor, PC06W-10-6S to pigtails cable, 10-ft, for Load Cells with PC connector (& 8162 Series), <20 ft 1
M084A104 1
