| Performance |
| Nominal Microphone Diameter |
1/4" |
1/4" |
|
| Frequency Response Characteristic (at 0° incidence) |
Free-Field |
Free-Field |
|
| Frequency Response (±2 dB) |
20 to 10000 Hz |
20 to 10000 Hz |
|
| Frequency Response (±5 dB) |
20 to 20000 Hz |
20 to 20000 Hz |
|
| Phase Match (100 Hz to 5 kHz) |
±5 ° |
±5 ° |
[1]
|
| Sensitivity (@ 250 Hz) |
45 mV/Pa |
45 mV/Pa |
|
| Sensitivity (±3 dB) (@ 250 Hz) |
-26.9 dB re 1 V/Pa |
-26.9 dB re 1 V/Pa |
|
| Inherent Noise (A Weighted) |
<30 dB |
<30 dB |
|
| Dynamic Range (3% Distortion Limit) |
>122 dB |
>122 dB |
|
| TEDS Compliant |
Yes |
Yes |
[2]
|
| Environmental |
| Temperature Range (Operating) |
+14 to +122 °F |
-10 to +50 °C |
|
| Temperature Effect on Output (-10 to +50 °C) |
<0.7 dB |
<0.7 dB |
[3]
|
| Electrical |
| Excitation Voltage |
18 to 30 VDC |
18 to 30 VDC |
|
| Constant Current Excitation |
2 to 20 mA |
2 to 20 mA |
|
| Output Bias Voltage |
5.5 to 14 VDC |
5.5 to 14 VDC |
|
| Output Impedance |
<150 Ohm |
<150 Ohm |
|
| Physical |
| Housing Material |
Stainless Steel |
Stainless Steel |
|
| Electrical Connector (Output) |
BNC Jack |
BNC Jack |
|
| Size - Diameter (overall) |
0.5 in |
12.7 mm |
|
| Size - Length (overall) |
2.62 in |
66.6 mm |
|
| Size - Diameter (head) |
0.28 in |
7 mm |
|
| Size - Length (head) |
1.10 in |
28 mm |
|
| Weight |
0.91 oz |
25.7 gm |
[3]
|
