New Two-Sensor ICP® Blast Pencil Probe

An innovative design for more accurate blast and shock wave measurements

May 25, 2017, Depew, NY – PCB’s new quartz, free-field, ICP® blast pressure pencil probe is a two-sensor pencil blast probe that provides time of arrival and the pressure time wave form for total impulse measurement, all in a single sensor. The Model 137B25 pencil probe is the first of its kind and features an extremely fast micro-second response time, with a resonant frequency greater than 400k Hz. This allows the sensor to be placed in close range to smaller explosive test articles and capture peak pressure, total impulse and shock speed.

The new pencil probe increases measurement accuracy and expands the 137B series of quartz, free-field ICP® blast pressure pencil probes, reducing the need for multiple single-sensor probes. The series is designed for a broad range of explosion, blast, and shock wave testing. Applications include measuring blast pressure in free-field and confined spaces, such as mines, and has been the blast pressure reference method for 50 years.

ICP® technology features integral microelectronics that provides a high signal-to-noise ratio. The low impedance and 5 volt output signal is capable of driving long cable runs hundreds of feet in length, to a safe zone for data acquisition, allowing the sensor to operate at frequencies up to 100 kHz with better data quality compared to piezoresistive pressure sensing technology. For more information visit about this innovative new sensor visit:
https://www.pcb.com/SensorsforTestMeasurement/PressureTransducers/BlastTransducers/ICPFree-FieldBlast.

Two-Sensor ICP® Blast Pencil Probe, Model 137B25 from PCB Piezotronics, Inc.

Created in 1990 by SAE Inc., Nadcap is administered by the not-for-profit Performance Review Institute (PRI). PRI is a global provider of customer-focused solutions designed to improve process and product quality by adding value, reducing total cost and promoting collaboration among stakeholders in industries where safety and quality are shared goals. PRI works closely with industry to understand their emerging needs and offers customized solutions in response. Learn more at www.p-r-i.org or contact PRI at PRI@p-r-i.org.

About PCB Piezotronics, Inc.

PCB Piezotronics Inc. is a designer and manufacturer of microphones, vibration, pressure, force, torque, load, and strain sensors, as well as the pioneer of ICP® technology. This instrumentation is used by design engineers and predictive maintenance professionals worldwide for test, measurement, monitoring, and control requirements in automotive, aerospace, industrial, R&D, military, educational, commercial, OEM applications, and more. Our Platinum Stock Sensors program ensures same day shipment of over 10,000 sensors that are covered by lifetime warranty. With a worldwide support team of Field Sales, Application Engineers, and Customer Service Representatives, PCB® proudly stands behind their products with the services you value most, including a 24-hour SensorLine^SM a global distribution network, and the industry's only commitment to Total Customer Satisfaction. Visit www.pcb.com for more information. PCB Piezotronics, Inc. is a wholly owned subsidiary of MTS Systems Corporation. Additional information on MTS can be found at www.mts.com.

PCB® and ICP® are registered trademarks of PCB Piezotronics, Inc.
