differential charge output pressure sensor with uht-12™ element, 6.0 pc/psi,+1400f, atex-csa approved

Charge Output Pressure Sensor

Model 176B12

Retrieving Price...

(Pricing valid only in the U.S.)

Add to Cart
Units in Stock Lead Times
More on the way Call for Lead Time
  • CE
  • IP

Differential charge output pressure sensor with UHT-12™ element, 6.0 pC/psi,+1400F, ATEX-CSA approved

  • Measurement Range: 725 psi (50 bar)
  • Sensing Element: UHT-12™
  • Temperature Range: -94 to 1400 °F (-70 to 760 °C)
  • Electrical Connector: LEMO
  • Weight: 4.6 oz (130 gm)

Additional configurations:

Specification Notes

[1] Low frequency response is determined by external signal conditioning electronics.
[2] Upper frequency response is calculated from Resonant Frequency.
[3] Zero-based, least-squares line method.
[4] Typical.
[5] Maximum.
[4] Typical.
[6] See PCB Declaration of Conformance PS058 for details.

English: SI:
Performance
Sensitivity (+/-20 %) 6 pC/psi 87 pC/bar
Sensitivity (+/-20 %) 6 pC/psi 87 pC/bar
Measurement Range 725 psi 50 bar
Maximum Pressure (Total) 5200 psi 358.5 bar
Resonant Frequency ≥100 kHz ≥100 kHz
Transverse Resonance >15 kHz >15 kHz
Frequency Response (±5.0 %) 20000 Hz 20000 Hz [1] [2]
Non-Linearity ≤1 % FS ≤1 % FS [3]
Environmental
Acceleration Sensitivity 0.0036 psi/g .00025 bar/g [5]
Acceleration Sensitivity .002 psi/g .00014 bar/g [4]
Temperature Range (Continuous) -94 to 1400 °F -70 to 760 °C
Temperature Range (Connector) -76 to 250 °F -60 to 121 °C
Temperature Response See Graph See Graph [4]
Hazardous Area Approval See Manual See Manual
Radiation Exposure Limit (Integrated Neutron Flux) 1E10 N/cm² 1E10 N/cm²
Radiation Exposure Limit (Integrated Gamma Flux) 1E8 rad 1E8 rad
Electrical
Output Polarity Differential Differential
Capacitance (with cable pin - pin) 150 pF 150 pF [4]
Resistance(Pin-Pin) (Room Temp) ≥1000000000 Ohm ≥1000000000 Ohm
Resistance(Pin-Case) (Room Temp) ≥1000000000 Ohm ≥1000000000 Ohm
Resistance(Pin-Pin) (1400°F/760°C) ≥50000 Ohm ≥50000 Ohm
Resistance(Pin-Case) (1400°F/760°C) ≥100000 Ohm ≥100000 Ohm
Physical
Sensing Element UHT-12™ UHT-12™
Sensing Geometry Compression Compression
Housing Material Nickel Alloy Nickel Alloy
Sealing Welded Hermetic Welded Hermetic
Electrical Connector LEMO LEMO
Cable Type Hardline Hardline
Cable Length 10 ft 3 m
Weight (with cable) 4.6 oz 130 gm [4]

* All specifications are at room temperature unless otherwise specified.

TempChart

Accessories
Supplied
PCS-1 Calibration of dynamic pressure sensors at 20% intervals to full scale, max 15 kpsi range. 0
065A71 Seal ring, silver plated 316L SST, .03" height, .430" OD, .376" ID 1
69862-01 1
